1000 SERIES

Fixed Frame

396 - 517 HP

1000 SERIES

Fixed Frame

396 - 517 HP

Highlights

  • The 1000 Series starts with AccuEngineering™: a foundation of intuitive, efficient design that results a more intelligent machine
  • The 12.4L, 6-cylinder MAN engine works together with the AccuDrive™ CVT through the Accu-VT™ powertrain for ultimate torque and exceptional power to the ground
  • Maneuverability and power to manage any task, from row crop planting and tillage to sprayer and wagon towing
  • The Challenger 10.4 touchscreen AccuTerminal™ brings your operation a new level of control, precision and productivity

Overview

You want intelligent farming? How about one tractor that does the job of two?

The Challenger® 1000 Series runs strong during spring applications, yet is versatile enough to come through the rest of the year. These fixed-frame tractors are built to handle the work of an articulated tractor, with the power and maneuverability to handle both grueling tillage work and intricate row-crop applications.

The engine and powertrain work in sync to maximize engine power at slow speeds so you can pull the heaviest implements through the toughest conditions with maximum torque and minimum fuel usage. And you always get optimized traction and flotation along with tremendous pulling power.

Features

MAN Engine

The six-cylinder, 12.4-liter MAN engine delivers an impressive 1,770 ft. lbs. of torque at 1,100 RPM. Developed using a high-torque-at- low speed engine concept to ensure the engine, transmission, fan and hydraulics function at maximum capacity, using the lowest engine speeds delivering maximum torque and low fuel consumption.

ACCUDRIVE

The optional twin-pump design provides a flow of up to 85 GPM, and offers incredible control and stability while reducing fuel consumption. Take full command of the MT900E’s formidable hydraulics system with up to 6 remotes and couplers.

ACCU-VT

Built with the most demanding jobsites in mind, the CAT 16-speed Powershift transmission gives you 8 gears in the working range while providing a transport speed of up to 25 MPH. Smoother shifting and better control helps you keep working longer.

Tractor Management Center

Though the Challenger 1000 Series tractor is a highly sophisticated machine, the Tractor Management Center makes it simple to operate. All functions, whether in the terminal or on the multi-function armrest, are color-coordinated to the controls that operate them, and the ergonomic design keeps all tasks and functions comfortably within the operator’s reach, reducing time and fatigue.

Air System

The Concentric Air System (CAS) cooling unit uses a unique front fan to pull in cold, dense air, accelerate it over the hood, and press it through the radiator. The CAS delivers optimal cooling power to each component, according to need, independent of engine speed.

SPECIFICATIONS

Model

Engine hp (kW)

PTO hp (kW)

Engine

Transmission

Hydraulics

1038

396 (291)

350 (261)

6-cylinder, 12.4 Liter, MAN

AccuDrive CVT

Standard 58 GPM ; Optional 116 GPM Dual-Pump, Dual-Circuit

1042

435 (320)

386 (288)

6-cylinder, 12.4 Liter, MAN

AccuDrive CVT

Standard 58 GPM ; Optional 116 GPM Dual-Pump, Dual-Circuit

1046

476 (350)

421 (314)

6-cylinder, 12.4 Liter, MAN

AccuDrive CVT

Standard 58 GPM ; Optional 116 GPM Dual-Pump, Dual-Circuit

1050

517 (380)

453 (338)

6-cylinder, 12.4 Liter, MAN

AccuDrive CVT

Standard 58 GPM ; Optional 116 GPM Dual-Pump, Dual-Circuit
